+Semaphores are hard to use in practice because quite low level Monitors provide an easier definition of concurrent objects at the level of Prog. Lang.
+
+It guarantees mutual exclusion.
+
+Inter-process synchronization is done through *conditions*, which are objects that provide the following operations:
+- ***wait*:** the invoking process suspends, enters into the condition's queue, and releases the mutex on the monitor
+- ***signal*:** if no process is in the condition's queue, the nothing happens. Otherwise
+	- reactivates the first suspended process, suspends the signaling process that however has a priority to re-enter the monitor (*Hoare semantics*)
+	- completes its task and the first process in the condition's queue has the priority to enter the monitor (after that the signaling one terminates or suspends) (*Mesa semantics*).
+
+#### A very typical use: Rendez-vous
+A soon as a process arrives at a barrier it needs to suspend and wait for every other process to reach the barrier.
+
+```
+monitor RNDV :=
+	cnt ∈ {0,…,m} init at 0
+	condition B
+	operation barrier() :=
+		cnt++
+		if cnt < m then
+			B.wait()
+		else
+			cnt <- 0
+		B.signal()
+		return
+```
+The last process wakes up one of the others, then he wakes up another one etc...
+Of course, `signal()` will have no effect on the last process who calls it.
+
+#### Monitor implementation through semaphores
+*Hoare semantics*
+
+- A semaphore MUTEX init at 1 (to guarantee mutex in the monitor)
+- For every condition C, a semaphore SEMC init at 0 and an integer $N_{C}$ init at 0 (to store and count the number of suspended processes on the given condition)
+- A semaphore PRIO init at 0 and an integer $N_{PR}$ init at 0 (to store and count the number of processes that have performed a signal, and so have priority to re-enter the monitor)
+
+Every monitor operation starts with `MUTEX.down()` and ends with `if NPR > 0 then PRIO.up() else MUTEX.up()`
+
+```
+C.wait() :=
+	NC++
+	if NPR > 0 then
+		PRIO.up()
+	else
+		MUTEX.up()
+	SEMC.down()
+	NC--
+	return
+
+C.signal() :=
+	if NC > 0 then
+		NPR++
+		SEMC.up()
+		PRIO.down()
+		NPR--
+```
+p.s. The wait **always** suspends, even if there is only a process.
+
+#### Readers/Writers problem, strong priority to Readers
+```
+monitor RW_READERS :=
+	AR, WR, AW, WW init at 0
+	condition CR, CW
+
+operation begin_read() :=
+	WR++
+	if AW != 0 then
+		CR.wait()
+		CR.signal()
+	AR++
+	WR--
+
+operation end_read() :=
+	AR--
+	if AR + WR = 0 then
+		CW.signal()
+
+operation begin_write() :=
+	if (AR+WR != 0 or AW != 0) then
+		CW.wait()
+	AW++
+
+operation end_write() :=
+	AW--
+	if WR > 0 then
+		CR.signal()
+	else
+		CW.signal()
+
+```
+
+#### Readers/Writers problem, strong priority to Writers
+```
+monitor RW_READERS :=
+	AR, WR, AW, WW init at 0
+	condition CR, CW
+
+operation begin_read() :=
+	if WW + AW != 0 then
+		CR.wait()
+		CR.signal()
+	AR++
+
+operation end_read() :=
+	AR--
+	if AR = 0 then
+		CW.signal()
+
+operation begin_write() :=
+	WW++
+	if (AR + AW != 0) then
+		CW.wait()
+	AW++
+	WW--
+
+operation end_write() :=
+	AW--
+	if WW > 0 then
+		CW.signal()
+	else
+		CR.signal()
+```
+
+#### Readers/Writers problem, a fair solution
+- after a write, all waiting readers are enabled
+- during a read, new readers must wait if writers are waiting
+```
+monitor RW_READERS :=
+	AR, WR, AW, WW init at 0
+	condition CR, CW
+
+operation begin_read() :=
+	WR++
+	if WW + AW != 0 then
+		CR.wait()
+		CR.signal()
+	AR++
+	WR--
+
+operation end_read() :=
+	AR--
+	if AR = 0 then
+		CW.signal()
+
+operation begin_write() :=
+	WW++
+	if (AR + AW != 0) then
+		CW.wait()
+	AW++
+	WW--
+
+operation end_write() :=
+	AW--
+	if WR > 0 then
+		CR.signal()
+	else
+		CW.signal()
+```
+This way nobody gets starved forever.
